Gas Heating Glass Tempering Furnace

Natural gas or liquefied petroleum gas heating glass tempering furnace has the advantage of significant energy saving improvement. The gas is richly found in nature, environment-friendly and clean. It is used for heating directly, so the loss caused by heat transfer is reduced. Compared with electrical heating, it saves more than 2/3 cost. As natural gas allows the glass sheets to be evenly heated at a lower temperature (670℃~690℃), the heating rate is improved, and the period for the glass staying on the roller is shortened. This enables the glass tempering furnace to minimize the chances of glass deformation, and improve the production rate and glass quality.

The gas heating glass tempering furnace is used to make flat toughened glass which is widely used in the fields of architecture, decoration, furniture, electronic apparatus, vehicles, ships, aviation, and more. The glass tempering equipment is also applicable to producing low-e glass (with the e>=0.1).

Technical Parameters

Model Max. Loading Area (mm) Min. Glass Size (mm) Thickness (mm) Gas Consumption (m2/h) Power Capacity (KVA)
PG1830 1830 ×3000 100 ×250 4~19 52 162
PG2136 2100 ×3660 100 ×300 4~19 75 269
PG2142 2100 ×4200 100 ×300 4~19 83 277
PG2436 2440 ×3660 100 ×300 4~19 83 307
PG2442 2440 ×4200 100 ×300 4~19 93 317
PG2450 2440 ×5000 150 ×350 4~19 110 340
PG2460 2440 ×6000 150 ×350 4~19 132 340

As a China-based gas heating glass tempering furnace manufacturer, Yuntong offers a vast range of products that includes cross bending glass tempering furnace, glass cross cutting machine, glass stacker, vertical glass washing machine, water pipe cooler, and more.

Terms of trade
1. Minimum order quantity (MOQ): one piece or complete plant
2. Delivery time: 3-6 months (except float glass production line)
3. Port of loading: port of Tianjin (Xingang)
4. Terms of payment: advance payment (30% TT) + payment before shipment (60% LC or TT) + the balance of payment (10% TT or LC) after final acceptance.
